          產品中心

          PRODUCTS

          壓敏電阻

          NTC熱敏電阻

          薄膜電容

          陶瓷電容

          溫度傳感器

          CWF-汽車類

          汽車鋰電池溫度傳感器
          Automotive Lithium Battery Temperature Sensor





              產品性能簡述
          Description of Product Performance





                          Code(代碼)                             B                             d                             D                             L1                             L2                             L3
                          Dimension
          (尺寸)
                          客戶自定義 Customized                             ≥50mm
                          產品性能                             1、線材規格:依客戶需求


                          Product  Performance                             1.Wire specification:By Customer's Requirements.
                          2、耐壓:AC1000V~AC2000V,3Sec                             2.Withstand voltage :AC1000V~AC2000V,3Sec
                          3、絕緣:DC500V Min 100MΩ,3Sec                             3.Insulation:DC500V Min 100MΩ,3Sec
                          4、使用溫度范圍: -30℃~105℃                             4.Operating temperature range:-30℃~105℃
                          -30℃~125℃                             -30℃~125℃
                          -30℃~150℃                             -30℃~150℃
          產品特點                             1、采用高精度、高穩定性元件封裝,測量溫差小,溫度更準確.                             Features                             1.Using  high-precision, high-stability component package, small temperature  difference and more accurate temperature
                          2、產品特殊防水、防潮處理,潮濕環境工作穩定。                             2.The  product has special waterproof and moisture-proof treatment, and it works  stably in humid environment.
                          3、產品安裝方便、抗寒、耐熱性能優良可長期負荷工作。                             3.The  product is easy to install, has good cold resistance and heat resistance, and  can work under long-term load.
                          產品用途                             適用于鋰電池溫控模塊                             Product  Usage                             apply  to lithium battery temperature control module








          汽車空調溫度傳感器
          Automotive air conditioner temperature sensor





              產品性能簡述
          Description of Product Performance







                          Code(代碼)                             d                             D                             L1                             L2


                              Dimension

                              (尺寸)

                          5mm Max                             8mm                             客戶自定義
          Customized
                          ≥50mm
                          產品性能                             1、線材規格:依客戶需求


                          Product  Performance                             1.Wire specification:By Customer's Requirements.
                          2、耐壓:AC1000V~AC2000V,3Sec                             2.Withstand voltage :AC1000V~AC2000V,3Sec
                          3、絕緣:DC500V  Min 100MΩ,3Sec                             3.Insulation:DC500V Min 100MΩ,3Sec
                          4、使用溫度范圍: -30℃~105℃                             4.Operating temperature range:-30℃~105℃
                          -30℃~125℃                             -30℃~125℃
                          -30℃~150℃                             -30℃~150℃
                          產品特點                             1、采用高精度、高穩定性元件封裝,測量溫差小,溫度更準確.                             Features                             1.Using  high-precision, high-stability component package, small temperature  difference and more accurate temperature
                          2、產品特殊防水、防潮處理,潮濕環境工作穩定。                             2.The  product has special waterproof and moisture-proof treatment, and it works  stably in humid environment.
                          3、產品安裝方便、抗寒、耐熱性能優良可長期負荷工作。                             3.The  product is easy to install, has good cold resistance and heat resistance, and  can work under long-term load.
                          產品用途                             適用于汽車空調溫控模塊                             Product  Usage                             apply  to Automotive air conditioning temperature control module









          汽車充電樁溫度傳感器
          Automotive charging pile temperature sensor



          產品性能簡述
          Description of Product Performance







                          Code(代碼)                             B                             D                             L1                             L2                             L3                             L4


                              Dimension

                              (尺寸)

                          25mm                             6mm                             客戶自定義
          Customized
                          ≥50mm
                          產品性能                             1、線材規格:依客戶需求


                          Product  Performance                             1.Wire specification:By Customer's Requirements.
                          2、耐壓:AC1000V~AC2000V,3Sec                             2.Withstand voltage :AC1000V~AC2000V,3Sec
                          3、絕緣:DC500V Min 100MΩ,3Sec                             3.Insulation:DC500V Min 100MΩ,3Sec
                          4、使用溫度范圍: -30℃~105℃                             4.Operating temperature range:-30℃~105℃
                          -30℃~125℃                             -30℃~125℃
                          -30℃~150℃                             -30℃~150℃
                          產品特點                             1、采用高精度、高穩定性元件封裝,測量溫差小,溫度更準確.                             Features                             1.Using  high-precision, high-stability component package, small temperature  difference and more accurate temperature
                          2、產品特殊防水、防潮處理,潮濕環境工作穩定。                             2.The  product has special waterproof and moisture-proof treatment, and it works  stably in humid environment.
                          3、產品安裝方便、抗寒、耐熱性能優良可長期負荷工作。                             3.The  product is easy to install, has good cold resistance and heat resistance, and  can work under long-term load.
                          產品用途                             適用于汽車充電樁溫控模塊                             Product  Usage                             apply  to Automobile charging pile temperature control module











          汽車風道模塊溫度傳感器
          Automotive air duct module temperature sensor



              產品性能簡述
          Description of Product Performance







                          Code(代碼)                             D                             L1                             L2
                          Dimension
          (尺寸)
                          客戶自定義 Customized                             ≥50mm
                          產品性能                             1、線材規格:依客戶需求


                          Product  Performance                             1.Wire specification:By Customer's Requirements.
                          2、耐壓:AC1000V~AC2000V,3Sec                             2.Withstand voltage :AC1000V~AC2000V,3Sec
                          3、絕緣:DC500V Min 100MΩ,3Sec                             3.Insulation:DC500V Min 100MΩ,3Sec
                          4、使用溫度范圍: -30℃~105℃                             4.Operating temperature range:-30℃~105℃
                          -30℃~125℃                             -30℃~125℃
                          -30℃~150℃                             -30℃~150℃
                          產品特點                             1、采用高精度、高穩定性元件封裝,測量溫差小,溫度更準確.                             Features                             1.Using  high-precision, high-stability component package, small temperature  difference and more accurate temperature
                          2、產品特殊防水、防潮處理,潮濕環境工作穩定。                             2.The  product has special waterproof and moisture-proof treatment, and it works  stably in humid environment.
                          3、產品安裝方便、抗寒、耐熱性能優良可長期負荷工作。                             3.The  product is easy to install, has good cold resistance and heat resistance, and  can work under long-term load.
                          產品用途                             適用于風道溫控模塊                             Product  Usage                             apply  to air duct temperature control module









          汽車蒸發器溫控模塊溫度傳感器
          Automotive evaporator temperature control module temperature sensor

              產品性能簡述
          Description of Product Performance







                          Code(代碼)                             d                             L1                             L2
                          Dimension
          (尺寸)
                          4mm                             客戶自定義
          Customized
                          ≥50mm
                          產品性能                             1、線材規格:依客戶需求


                          Product  Performance                             1.Wire specification:By Customer's Requirements.
                          2、耐壓:AC1000V~AC2000V,3Sec                             2.Withstand voltage :AC1000V~AC2000V,3Sec
                          3、絕緣:DC500V  Min 100MΩ,3Sec                             3.Insulation:DC500V Min 100MΩ,3Sec
                          4、使用溫度范圍: -30℃~105℃                             4.Operating temperature range:-30℃~105℃
                          -30℃~125℃                             -30℃~125℃
                          -30℃~150℃                             -30℃~150℃
                          產品特點                             1、采用高精度、高穩定性元件封裝,測量溫差小,溫度更準確.                             Features                             1.Using  high-precision, high-stability component package, small temperature  difference and more accurate temperature
                          2、產品特殊防水、防潮處理,潮濕環境工作穩定。                             2.The  product has special waterproof and moisture-proof treatment, and it works  stably in humid environment.
                          3、產品安裝方便、抗寒、耐熱性能優良可長期負荷工作。                             3.The  product is easy to install, has good cold resistance and heat resistance, and  can work under long-term load.
                          產品用途                             適用于蒸發器溫控模塊                             Product  Usage                             apply  to evaporator temperature control module











          汽車空調溫控模塊溫度傳感器
          Automotive air-conditioning temperature control module temperature sensor



          產品性能簡述
          Description of Product Performance







                          Code(代碼)                             d                             D                             L1                             L2                             L3
                          Dimension
          (尺寸)
                          4mm Max                             6mm max                             客戶自定義
          Customized
                          ≥50mm
                          產品性能                             1、線材規格:依客戶需求


                          Product  Performance                             1.Wire specification:By Customer's Requirements.
                          2、耐壓:AC1000V~AC2000V,3Sec                             2.Withstand voltage :AC1000V~AC2000V,3Sec
                          3、絕緣:DC500V Min 100MΩ,3Sec                             3.Insulation:DC500V Min 100MΩ,3Sec
                          4、使用溫度范圍: -30℃~105℃                             4.Operating temperature range:-30℃~105℃
                          -30℃~125℃                             -30℃~125℃
                          -30℃~150℃                             -30℃~150℃
                          產品特點                             1、采用高精度、高穩定性元件封裝,測量溫差小,溫度更準確.                             Features                             1.Using  high-precision, high-stability component package, small temperature  difference and more accurate temperature
                          2、產品特殊防水、防潮處理,潮濕環境工作穩定。                             2.The  product has special waterproof and moisture-proof treatment, and it works  stably in humid environment.
                          3、產品安裝方便、抗寒、耐熱性能優良可長期負荷工作。                             3.The  product is easy to install, has good cold resistance and heat resistance, and  can work under long-term load.
                          產品用途                             適用于空調溫控模塊                             Product  Usage                             apply  to air-conditioning temperature control module
